Electric Air Brake Compressor for Commercial Vehicles

electric air brake compressor for truck, bus

We supply the advanced electric air brake compressor for commercial vehicles (PHEV, HEV, BEV), including trucks, buses, vans, and more. Our two-stage oil-free electric air brake compressors ensure the delivery of oil and water-free air, eliminating concerns associated with oil emulsification, leaks, and fire hazards. Its innovative structural design minimizes energy wastage during the compression process, thereby optimizing overall efficiency.

Furthermore, our air brake compressors exhibit exceptional environmental adaptability, reliably operating in a wide range of extreme weather conditions, from -40°C to +65°C. This reliability ensures uninterrupted performance, even in the most challenging environments.

Email: contact@brogenevsolution.com

Brogen Electric Air Brake Compressor Features

Our air brake compressor systems have been in mass production and deployment since 2012, with some units achieving an operational mileage of over 300,000 km. They are widely used by leading domestic and international OEMs, including Foton, Geely Commercial Vehicles, BYD, SANY, Zoomlion, JMC, JAC, and others. Applicable vehicle types include 4×2, 6×4, 8×4, and 10×8 configurations, such as tractors, dump trucks, construction vehicles, light trucks, municipal vehicles, logistics vehicles, and city buses.

Lightweight Design

Features a cast aluminum housing, reducing weight by over 15% compared to iron-based structures.

Maintenance-Free Design

Incorporates self-lubricating materials and grease-lubricated bearings for a completely maintenance-free lifecycle.

Comfort-Oriented Design

Delivers low noise and vibration levels to enhance overall ride comfort.

Extended Service Life

Piston cylinder inner walls are mirror-finished to minimize wear and ensure long operational life.

High Protection

Utilizes high-performance adhesive-coated sealing plates, achieving superior ingress protection.

Enhanced Reliability

Equipped with a two-stage supercharging design to minimize high-pressure displacement degradation.

Brogen Electric Air Brake Compressor Offerings

*Please note that these parameters are for reference only. For detailed specifications, please contact our sales team. Additional options are available upon request. Email: contact@BrogenEVSolution.com

ModelOE-B001OE-B002OE-B003OE-B004OE-B005OE-B006OE-B007OE-B009
Rated exhaust120 L/min240 L/min380 L/min160 L/min200 L/min240 L/min300 L/min160 L/min
Rated exhaust pressure1 Mpa1 Mpa1 Mpa1 Mpa1 Mpa1 Mpa1 Mpa
Exhaust pressure1.2 Mpa1.2 Mpa1.2 Mpa1.2 Mpa1.2 Mpa1.2 Mpa1.2 Mpa1 Mpa
Dimensions340*275*275 mm500*285*320 mm560*335*370 mm560*335*370 mm495*385*355 mm495*385*355 mm495*385*355 mm363*274*281 mm
Motor power1.5 kW3 kW4 kW1.6 kW2.2 kW3.0 kW3.0 kW1.8 kW
Weight26 kg48 kg65 kg65 kg45 kg45 kg45 kg25.5 kg
Operating temperature-40°C ~ +60°C-40°C ~ +60°C-40°C ~ +60°C-40°C ~ +60°C-40°C ~ +60°C-40°C ~ +60°C-40°C ~ +60°C-40°C ~ +60°C
Protection classIP67IP67IP67IP67IP67IP67IP67IP68

Technical Advantages

Item
Our Oil-Free Piston Air Brake Compressor
Screw Air Compressor
Rotary Vane Compressor
Type of lubricating oil
No need of lubricating oil
Special screw compressor oil
Special vane compressor oil
Lubricating oil consumption
Relatively high
Lubricating oil emulsification and deterioration
Prone to emulsification and deterioration
Lubricating oil environmental adaptability
Easily affected by external air contamination
Oil-gas separator
Must be used, with a short service life
Lubricating oil temperature control
Required
Impact of lubricating oil on driving safety
If maintenance is not performed promptly, lubricating oil can contaminate the air system, causing rubber components to swell and age, which may lead to brake system failure
Compression efficiency
High
Average
High
Space occupation
Small
Average
Small
Weight
Relatively light
Relatively light
Relatively light
Energy consumption
Average
Average
High
Protection level
IP67
IP56
Air quality
Good
Poor compressed air quality, with high oil discharge
Lifespan
Long
Average
Relatively short
Maintenance experience
No special maintenance experience required
Higher maintenance experience required
Maintenenace cost
Low
High

Oil-Free Electric Air Brake Compressor With Two-Stage Compression: Working Principle

  1. Filtered air flows into the air compressor through the intake pipe.
  2. Within the first-stage cylinder, the gas experiences primary compression.
  3. The primary compressed gas is cooled by the intercooler and directed into the secondary cylinder for secondary compression.
  4. Following the secondary compression, the gas is discharged from the air compressor and routed into the air storage tank through the dryer.
oil free electric air brake compressor
structure features of brogen electric air brake compressor

Oil-Free Two-Stage Electric Air Brake Compressor: Structure Features

  • Utilizes a two-stage compression system to enhance exhaust pressure, lower exhaust temperature, and improve volumetric efficiency. Paired with a high-performance PMSM, it offers powerful startup capability, optimized efficiency, and significant energy savings.
  • Features advanced self-lubricating composite polytetrafluoroethylene material for piston rings, achieving a completely oil-free operation. This design eliminates the risk of “oil carryover” affecting the piping, greatly extending the lifespan of dryers and other air valves, and supporting green, energy-efficient performance.

Our System Benefits

  • Self-lubricating materials for oil-free compression and no pollution
  • Two-stage compression system for high efficiency, low energy consumption, and exceptional reliability
  • Advanced noise reduction technology for minimal operational noise
  • Compact design for easy installation and convenient chassis layout
  • Shock absorption design for smooth operation with minimal vibration
  • Rated IP67 for dust and water resistance
  • Entirely oil-free design simplifies maintenance and reduces costs
air-brake-compressor-for-electric-heavy-truck

Case Studies

our air compressors applied on new energy coaches

Our air compressors have been integrated into electric coaches, ensuring clean, stable air pressure throughout. Following installation, we rigorously tested all components reliant on air compressors on-site, observing improved functionality and heightened sensitivity. Remarkably, even after covering 27,714 kilometers, there hasn't been a single operational glitch.

air compressor application - 2

These air compressors are also installed on HEV city buses. Currently, the mileage has exceeded 40,000 kilometers, and the vehicles are operating smoothly. During operation, there is no noticeable vibration from the air compressors at any position within the vehicle. Additionally, with external environmental noise excluded, the measured interior noise level during air compressor operation ranges from 50 to 55 dB.

air compressor application - 3

For this project, the public transit company worked with a technology company to replace their oil-based air compressors with our oil-free ones. This strategic shift not only resolved oil leakage but also slashed the failure rates. With approximately 90,000 kilometers logged on vehicles equipped with our compressors, subsequent tests confirmed their seamless operation. Improved sensitivity across pressure-related components further validates their performance enhancement.
