Electric Boat Motor Solutions

We provide advanced electric propulsion systems to support the electrification of modern vessels. Our electric boat motor solutions are engineered for compactness, ensuring easy installation and optimal use of space. They are ideally suited for both main propulsion and auxiliary thruster applications.

Featuring low noise and minimal vibration, our systems significantly enhance onboard comfort while maintaining smooth and efficient operation. With high energy efficiency, robust energy-saving performance, and compliance with industry-standard certifications, our solutions deliver reliable, sustainable propulsion for the evolving maritime sector.

Email: contact@brogenevsolution.com

Brogen Electric Boat Motor Solution Features

Cross-dimensional deep simulation & Full control over development quality

Product Series

0 +

Design Specifications

0 +

Key Indicators

0 +

PCR & FMEA Libraries

0 +

Leading the Way in Green Marine Technologies

At the forefront of sustainable maritime innovation, we utilize cutting-edge simulation and analysis techniques to deliver reliable, efficient, and eco-friendly marine electrification solutions. Based on Maxwell, we streamline the entire development process—from system modeling and analysis to offline and real-time simulations—significantly reducing development time and enhancing overall efficiency. We also integrate advanced multiphysics coupling analysis to optimize electric boat motor performance.

Compact & Lightweight

Save installation space for small ships

Versatile Power Ranges

Available in air-cooled or water-cooled models, with a power range from 5 kW to 400 kW

Maintenance-Free Bearings

Reduces upkeep and extends motor lifespan

Wide Applications

Suitable for a wide range of vessels, meeting diverse speed and ppower requirements

Our Offerings of Electric Boat Motor Solutions

1. Electric Outboard Motor With Battery

Our electric outboard motors for boats range from 6 kW (10 hp) to 45 kW (60 hp). They represent a significant advancement in electric propulsion technology, offering a cleaner and more efficient power solution for various types of vessels. By incorporating advanced electric technology, our electric outboard motors significantly reduce operating noise, minimize maintenance needs, and provides a sustinable, user-friendly propulsion option.

Our Electric Outboard Motor Solution Benefits

Low-Noise Operation
Ensures a quieter and smoother cruising experience, enhancing onboard comfort and reducing noise pollution.
Simplified Maintenance
Reduces the frequency of routine maintenance, thereby lowering long-term operational costs and improving vessel uptime.
Precise Positioning and Tracking
Equipped with an efficient tracking system for real-time monitoring of the vessel's status.
Closed-Loop Liquid Cooling System
Employs innovative cooling technology to ensure stable performance even under continuous high loads.
Intelligent Operation
Incorporates vessel networking capabilities, enabling intuitive touch control and dual-motor synchronization for a user-friendly operation.
Eco-friendly and Energy-Efficient
Reduces carbon emissions and minimizes environmental impact, supporting the sustainable development of green maritime navigation.
Versatile Application
Ideal for a wide range of applications, from leisure boating to professional operations, the electric outboard motor is the perfect choice for vessels that prioritize efficiency, environmental sustainability, and low noise.

Electric Outboard Motor Solution Technical Parameters

*Please note that these parameters are for reference only. For detailed specifications, please contact our sales team. Additional options are available upon request. Email: contact@BrogenEVSolution.com

Model: OE209
Input power: 6 kW
Equivalent power: 10 hp
Rated voltage / current: 64 V / 95 A
Battery: 8.5 kWh
Machine weight: 38 kg
Battery weight: 70 kg
Controller: Rudder control
Propeller: 3-9.25″x8″，3-blade propeller, metal
Rated speed: 6000 rpm
Gear ratio: 27:13
Motor type: PMSM
Tailgate height: 380 mm
Battery life: 6 hours at 5 km/h; 3 hours at 10 km/h; 1 hour at 20 km/h

Model: OE215
Input power: 10 kW
Equivalent power: 20 hp
Rated voltage: 320 V
Battery: 42.5 kWh
Machine weight: 60 kg
Battery weight: 362 kg
Controller: Rudder control
Propeller: 13.6″ x 15″，3-blade propeller, metal
Rated speed: 6000 rpm
Gear ratio: 26:13
Motor type: PMSM
Tailgate height: 480 mm
Battery life: 10 hours at 8 km/h; 6.5 hours at 12 km/h; 3.5 hours at 20 km/h

Model: OE230
Input power: 30 kW
Equivalent power: 40 hp
Rated voltage: 154 V
Battery: 35 kWh
Machine weight: 90 kg
Battery weight: 245 kg
Controller: Rudder control
Propeller: 13.6″ x 15″，3-blade propeller, metal
Rated speed: 5500 rpm
Gear ratio: 27:13
Motor type: PMSM
Tailgate height: 550 mm
Battery life: 6.5 hours at 8 km/h; 3.5 hours at 14 km/h; 1 hour at 24 km/h

Model: OE245
Input power: 45 kW
Equivalent power: 60 hp
Rated voltage: 320 V
Battery: 42.5 kWh
Machine weight: 100 kg
Battery weight: 362 kg
Controller: Rudder control
Propeller: 13.6″ x 15″，3-blade propeller, metal
Rated speed: 6000 rpm
Gear ratio: 27:13
Motor type: PMSM
Tailgate height: 550 mm
Battery life: 4 hours at 14 km/h; 2.5 hours at 25 km/h; 1 hour at 38 km/h

2. Electric Inboard Motor for Boat

We offer a wide range of air-cooled and water-cooled electric inboard boat motors, complete with controllers, available in power ratings from 11.8 kW (15.8 hp) to 400 kW (536 hp). Our electric boat motors cater to diverse ship types, speed requirements, and power needs. Each system undergoes rigorous testing to ensure optimal safety and quality.

Electric Inboard Motor Solution Technical Parameters

*Please note that these parameters are for reference only. For detailed specifications, please contact our sales team. Additional options and controllers are available upon request. Email: contact@BrogenEVSolution.com

Model	Power / 750 rpm	Power / 1000 rpm	Power / 1500 rpm	Recommended voltage platform
1030MDS	11.8 kW / 15.8 hp	15.7 kW / 21 hp	23.7 kW / 31.8 hp	360 VDC
1040MDS	12.5 kW / 16.8 hp	16.8 kW / 22 hp	25 kW / 33 hp	360 VDC
2040MDS	15 kW / 20 hp	20 kW / 26 hp	30 kW / 40 hp	360 VDC
1050MDS	27.5 kW / 36 hp	36.6 kW / 49 hp	55 kW / 73 hp	540 VDC
3060MDS	41 kW / 55 hp	55 kW / 73.76 hp	82 kW / 110 hp	540 VDC
1080MDS	45 kW / 60 hp	60 kW / 80 hp	90 kW / 120 hp	540 VDC
2080MDS	62 kW / 83 hp	83 kW / 111 hp	124 kW / 166 hp	540 VDC
2090MDS	102 kW / 136 hp	136 kW / 182 hp	204 kW / 273 hp	540 VDC
3090MDS	200 kW / 268 hp	266 kW / 356 hp	400 kW / 536 hp	540 VDC
1081MDS	31.4 kW / 42 hp	42 kW / 56 hp	63 kW / 84 hp	540 VDC
2081MDS	51.8 kW / 69 hp	69 kW / 92 hp	104 kW / 139 hp	540 VDC
1091MDS	66 kW / 88 hp	88 kW / 118 hp	132 kW / 177 hp	540 VDC
2091MDS	97 kW / 130 hp	130 kW / 174 hp	195 kW / 261 hp	540 VDC
1002MDS	142 kW / 190 hp	189 kW / 253 hp	283 kW / 379 hp	540 VDC

Electric Inboard Motor Controller Technical Parameters

The relevant motor controller will be configured based on the specific motor requirements discussed with the customer.

How We Work

Navigating Our Process

Demand Analysis & Project Evaluation

Once we receive your inquiry, our experts will connect with you within two business days to understand your specific requirements for the EV solution and conduct an initial feasibility evaluation of your project.

Project & Technical Coordination

If the project is deemed feasible, our engineering team will collaborate closely with your team on both hardware and software aspects to develop a viable solution. We will also provide a detailed quotation based on the technical requirements.

Development, Manufacturing & Testing

For customized or modified systems, we proceed with product development, including hardware and software adaptations. Our EV systems undergo rigorous testing to ensure quality, reliability, and full functionality before deployment.

In-Time Global Shipping & Delivery

We have established strong partnerships with international shipping providers, ensuring safe and timely delivery of products to your specified location. This guarantees a smooth and efficient deployment of your EV project.

Full-Stage Remote/Onsite Technical Support

We provide technical support throughout the entire project lifecycle, including consultancy, hardware and software development, calibration, and both onsite and remote debugging, ensuring optimal performance and long-term success.
