100kW / 200kW Electric Truck Motor for 14-Ton to 18-Ton Electric Trucks
This 100kW / 200kW electric truck motor is specifically designed for electric trucks and municipal vehicles — including water trucks, garbage trucks, and street sweepers — ranging from 14 to 18 tons. It has been supplied to leading domestic truck manufacturers and is currently utilized in over 100 models, with sales exceeding 4,500 sets.
The e-powertrain system integrates the motor with the gearbox, and, optionally, the motor controller, offering a compact design that enhances vehicle layout efficiency.
Technical Parameters
| Motor Parameters | ||||
| Rated / Peak Power | 100 / 200 kW | |||
| Rated / Peak Torque | 500 / 1100 N.m | |||
| Maximum Speed | 3500 rpm | |||
| Gearbox Parameters | ||||
| Gear | 1 | 2 | 3 | 4 |
| Speed Ratio | 6.61 | 3.52 | 1.89 | 1 |
| System Parameters | ||||
| System Maximum Output Torque | 7000 N.m | |||
| Total Weight | 250 kg | |||
| Dimensions | 680*500*567 mm | |||
| PTO Parameters (Optional) | ||||
| Total Speed Ratio | 1.02 | |||
| Maximum Output Torque | 300 N.m | |||
| Maximum Output Power | 60 kW | |||
Example Configuration
- Vehicle model type: 18-ton pure electric dump truck
- Maximum vehicle speed: 89 km/h
- CLTC range: 300 km
- Battery energy: 246.67 kWh
- Battery voltage: 540 V
